机械密封通用安装说明：

1.轴弯曲度最大不得超过0.05mm。

2.轴在安装机械密封处的振摆量不得大于0.1mm。

3.轴的轴向窜动量不允许大于0.5mm。

4.安装机械密封部位轴制造公差为h8，光洁度1.6。

5.安装动环密封圈的轴（轴套）端部以及安静环密封圈的密封压盖（或壳体）的端部应做成倒角并修光。

6.部件内各零件均符合图纸设计要求。

7.上紧压盖时应在联轴器找正后进行，压紧螺丝应均上紧，防止法兰面偏斜。

8.弹簧的压缩量按图纸规定进行允许误差2mm。

9.动环安装后必须保证动环能在主轴上灵活移动。

Installation Instructions

1.Bending axis of the largest not more than 0.05mm.

2.Axis in the installation of the mechanical seal should not be run out Greater than 0.1mm.

3.Axis of the axial movement of not more than 0.5mm.

4.Installation of mechanical shaft seal parts manufacturing tolerance for h8,Finish 1.6.

5.Installation of the shaft sealing ring dynamic(bushings),as well as the end of Quiet ring ring seal gland(or shell)End chamfering and repair should be made light.

6.Various other parts of the design requirements are in line with the drawings.

7.Pressed into the cover should be in the coupling is after,Clamping screws are on the bear should be to prevent the flange surface deflection.

8.Spring compression of the drawings by provisions allowing misuse Poor ±2mm.

9.Dynamic ring after installation must ensure that dynamic in the ring spindle Flexible mobile.

安装注意事项说明

1、装配要干净光洁、轴、密封端盖等倒角要修整光滑，端盖要砂光擦亮。

2、推进组件时，要防止O形密封圈损伤。主要损伤形式有掉块、裂口、碰伤、卷边和扭曲。

3、组装成动环或静环组件后，用手按动补偿环，检查是否装到位，是否灵活；弹性开口环（有些结构的机械密封中，弹性开口环对补偿环作轴向定位）是否定位可靠10拧螺栓压紧端盖时，要用力均匀、对称、小心，分几次紧完，不可一次紧定，以免偏斜甚至压碎静环。

警告：开机前确保介质！

禁止干磨！
